RJ-51D173-PW
RJ
RJ-51D173-PW
8500CYCLES - 15YEARS WARRANTY - FACTORY PRICE
FOSHAN RJ is a leading Powerwall Home Battery Manufacturer in China for over 16years, We focus on lithium iron phosphate battery, known as lifepo4 battery, which is the longest lifecycles and safest chemistry of all kinds of lithium battery. Our Whole House Battery Backup reach 8500cycles at 100%DOD. We offer very goo
price with top quality, our powerwall home battery is 15years warranty. our battery compatible with nearly all kinds of Inverters, SMA, Solar edge, Sunny island, Deye,Growatt, Goodwe, Outback etc. look for distributors
| Model | RJ-51D173-PW |
| Norminal Power(KWh) | 8.8KWh |
| Norninal Capacity(Ah) | 172Ah |
| Norninal Voltage(V) | 51.2V |
| Material Type | Lithium Battery (LiFePO4) |
| Dimensions (mm) | 570*161*720mm |
| Weight(Kg) | 75Kg |
| Discharging Voltage(V) | 40~58.4 V |
| Max Charging | 100A |
| Continuous Discharging (A) | 100A |
| Peak Discharging (A) | 200A |
| Expansibility | max 16pcs |
| Installation Methode | Floor Mounted |
| Communication Port | RS485/CAN |
| Working Temperature(℃) | -20~65℃ |
| Humidity | 0-95% RH |
| IP Grade (IP) | 0-95% RH |
| Altitude | ≤5000m |
| Authentication Level | TUV/CE/UN38.3 |
| Design Life(year) | 30+ years |
| Cycle Life (cycle) | 8500Times |
Project | Content | default parameters | Whether can set up |
Overcharge Protection | Alarm voltage | 3600mV | Y |
Protection voltage | 3700mV | Y | |
Protection latency time | 1.0S | Y | |
Over-discharge Protection | Alarm voltage | 2800mV | Y |
Protection voltage | 2700mV | Y | |
Protection latency time | 1.0S | Y | |
Charging Over-current Protection | Alarm current | 105A | Y |
Protection current | 110A | Y | |
Protection latency time | 1.0S | Y | |
Short Circuit Protection | Protection current | ≥350A | Y |
Protection latency time | ≤300uS | Y | |
MOSFET High-temperature Protection | Alarm temperature | 90℃ | Y |
Protection temperature | 115℃ | Y | |
Batteries Temperature Protection | Low temperature charging alarm/protection temperature | 0℃/-5℃ | Y |
High temperature charging alarm/protection temperature | 60℃/65℃ | Y | |
The Environmental Temperature Alarm | Low-temperature alarm/protection temperature | -15℃/-20℃ | Y |
High-temperature alarm/protection temperature | 65℃/75℃ | Y | |
A Serial Port Communication | Isolated RS - 232 / RS - 485 | / | Y |
Bluetooth | Bluetooth function | / | optional |
Charging Current Limiting Function | Charging current limiting current | 20A | optional |
Display Screen | Display function | / | optional |
RJ TECH Batteries More Model Available
| Home Battery Powerwall Battery | |||||||
| Rated Energy | Capacity | Voltage | Installation | Communication | Weight | lifespan | Cylces |
| 5KWH | 100AH | 48V | Wall/Floor | RS485/Bluetooth | 50KG | 30years | 8000times |
| 10KWH | 200AH | 48V | Wall/Floor | RS485/Bluetooth | 100KG | 30years | 8000times |
| 15KWH | 300AH | 48V | Wall/Floor | RS485/Bluetooth | 150KG | 30years | 8000times |
| 20KWH | 400AH | 48V | Wall/Floor | RS485/Bluetooth | 200KG | 30years | 8000times |
| 25KWH | 500AH | 48V | Wall/Floor | RS485/Bluetooth | 250KG | 30years | 8000times |
| 30KWH | 600AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 300KG | 30years | 8000times |
| 35KWH | 700AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 350KG | 30years | 8000times |
| 40KWH | 800AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 400KG | 30years | 8000times |
| 45KWH | 900AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 450KG | 30years | 8000times |
| 50KWH | 1000AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 500KG | 30years | 8000times |
| 55KWH | 1100AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 550KG | 30years | 8000times |
| 60KWH | 1200AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 600KG | 30years | 8000times |
| 65KWH | 1300AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 650KG | 30years | 8000times |
| 70KWH | 1400AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 700KG | 30years | 8000times |
| 75KWH | 1500AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 750KG | 30years | 8000times |
| 80KWH | 1600AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 800KG | 30years | 8000times |
| 85KWH | 1700AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 850KG | 30years | 8000times |
| 90KWH | 1800AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 900KG | 30years | 8000times |
| 100KWH | 2000AH | 48V | Wall/Floor/Rack | RS485/Bluetooth | 1000KG | 30years | 8000times |
| Factory Price- Customization available- MOQ1pcs-15Years warranty | |||||||
RJ TECH Batteries Certifications
RJ TECH Batteries Installation Cases
What Clients Say about RJ TECH Batteries
RJ TECH ISO9001 Factory Automatic Production Line
RJ TECH Batteries Wooden Package
RJ TECH Batteries Compatible with All Inverters
