RJ-LFP-60250-P
RJ
RJ-LFP-60250-P
8000CYCLES - 10YEARS WARRANTY - FACTORY PRICE
As professional lithium battery suppliers, RJ TECH provide customers with lithium battery solutions for E-motorcycles, 4 Wheeler bike, E-Scooters, ATV, UTV, Dirt Bike, off road buggies, Sportsmotors, electric bicycles, electric motorcycles, lithium forklift battery, Floor Sweeper Battery, tour buses, golf carts, e-bikes, e-scooters, robots, ship engines, power storage, car audio, power wheels, solar panels, marine cranking, monitors, trolling motors, mobility scooters, UPS, etc.
RJ lithium batteries have the characteristics of high energy density, long cycle life, high safety performance, product consistency, and can adapt to a wide range of environments, Compact, Light weight, fast charging, powerful discharging for AC, DC motor, More torque, longer range, much Faster.
Features
• More than 8000 Cycles
• Battery modules available for parallel and series for higher voltage and capacity
• BMS Passive cell balance funciton
• IP65, IP66 water proof, dust proof, Temperature monitoring
• Customization for Size and Discharge and charge rate
• Free of Maintenance, contains no poisonous material
• No leakage, no hazardous chemistry
• Quick delivery
• Lighter in weight, smaller in size to save space.
• Powerfull to increase robust operation
• Fast charging and high power discharge rate available
• No need to add water nor worry about maintenance.
| Item | Specification | Note |
| Nominal Voltage: | 60V | |
| Nominal Capacity: | 250Ah | |
| Discharge Cut-Off: | 47.5V | |
| Charge Cut-Off: | 69.3V | |
| Charge Current: | 200A | |
| Cont. Discharge: | 200A | |
| Peak Discharge: | 400A | |
| Impedance: | ≤200mΩ | |
| Charge Temperature: | 0℃ - 45℃ | |
| Discharge Temperature: | -20℃ - 60℃ | |
| Charge Method: | CC/CV | |
| Life Cycle: | >8000 times | 80% DOD, Max. 100% DOD |
| BMS: | With BMS | |
| Dimension: | Flexible | Any dimension can be customized |
| Weight: | 130KG |
Item
| Content | Criterion |
Over charge Protection
| Over charge detection voltage | 3.6~4.25V |
| Over charge detection delay time | 0.1 S ~ 6S | |
| Over charge release voltage | 3.5~4.25V | |
| Over discharge protection | Over discharge detection voltage
| 2.0~3.3V |
| Over discharge detection delay time | 0.1 S ~ 6S | |
| Over discharge release voltage | 2.1~3.4V | |
| Charge Over current protection | Charge Over current detection current | 1~100A |
| Charge Over current detection delay time | 0.02S~ 6S | |
Discharge Over current protection | Discharge Over current detection current | 1~600A |
Discharge Over current detection delay time
| 0.02S~ 6S | |
Short protection | Short protection detection delay time | 100 u S |
| Detection condition | B+ P-0.2 Omh | |
| restore | Cut off load | |
| Interior Resistance | Main loop electrify resistance | 2 OMh(50A) |
| Currentconsumption | Current consume in normal operation | 1.5mA Type |
| Currentconsumption | Current consume in sleep operation | 2 uA Type |
