RJ-LFP-3640-E
RJ
RJ-LFP-3640-E
RJ is a lithium battery Manufacturer for over 16years, recognized by customers from Australia,Europe and North America.We offer Top quality with very good price for lithium lifepo4 batteries cells!
Norminal Power(KWh) | 1536Wh |
Norninal Capacity(Ah) | 40Ah |
Norninal Voltage(V) | 36V |
Type | LiFePO4 Battery |
Dimensions (mm) | Customized |
Weight(Kg) | 15Kg |
Cut off Discharging Voltage(V) | 30V |
Cut off Cischarging Voltage(V) | 43.8V |
Charging Current | 15A |
Discharging Current (A) | 40A |
Working Temperature(℃) | 0~55℃ |
Shelf Temperature(℃) | -20~70℃ |
Humidity | 0-95% RH(Non-condensing) |
IP Grade (IP) | 0-95% RH(Non-condensing) |
Altitude | ≤3000m |
Authentication Level | TuV/CE/UN38.3 |
Design Life(year) | 20+ years (@25℃/77℉) |
Cycle Life (cycle) | >6000Times |
Features
• More than 6000 Cycles @80% DOD ( depth of discharge)
• Battery modules available for parallel and series for higher voltage and capacity
• BMS Passive cell balance funciton
• IP66, IP67, water proof, dust proof, Temperature monitoring
• Customization for Size and Discharge and charge rate
• Free of Maintenance, contains no poisonous material
• No leakage, no hazardous chemistry
• Quick delivery
• Lighter in weight, smaller in size to save space.
• Powerfull to increase robust operation for your marine boat or RV
• Fast charging and high power discharge rate available
• No need to add water nor worry about maintenance.
• We offer 5years regular warranty and it can be extended up to 10 years.
No. | Item | Test Item | Creterion | |
1 | Voltage | Charging Voltage | DC:14.4V CC/CV | |
Balance voltage for single cell | 3.50±0.025V | |||
2 | Current | Balance voltage for single cell | 35±5mA | |
Current consumption | ≤50μA | |||
Charging current | 15A | |||
Rated continuous discharging current | 40A (Peak 80A) | |||
3 | Over charge Protection | Over charge detection voltage for single cell | 3.65V±0.025V | |
Over charge detection delay time | 0.7S—1.3S | |||
Over charge release voltage for single cell | 3.550±0.05V | |||
4 | Over discharge Protection | Over discharge detection voltage for single cell | 2.50V±0.07V | |
Over discharge detection delay time | 1.6±0.5S | |||
Over discharge release voltage for single cell | 3.00±0.75V | |||
5 | Over current Protection | Over current detection current | 500±50A | |
Over current detection delay time | 1.6±0.5S | |||
Release condition | Cut load | |||
6 | Short Protection | Detection condition | Exterior short circuit | |
Detection delay time | 230uS—500uS | |||
Release condition | Cut load | |||
7 | Resistance | Protection circuitry (MOSFET) | ≤60mΩ | |
8 | Temperature | Operating Temperature Range | -40~+85℃ | |
Storage Temperature Range | -40~+85℃ |
More Model Available
LIFEPO4 | Dimensions | Weight | With BMS | RS485/Bluetooth | Cycles | Warranty |
36V 10AH | 165*125*175mm | 6.5kg | Yes | Available | 6000times | 5years |
36V 20AH | 240*158*190mm | 9kg | Yes | Available | 6000times | 5years |
36V 30AH | 195*165*175mm | 14kg | Yes | Available | 6000times | 5years |
36V 40AH | 330*175*220mm | 18kg | Yes | Available | 6000times | 5years |
36V 50AH | 330*175*220mm | 22kg | Yes | Available | 6000times | 5years |
36V 60AH | 485*175*240mm | 30kg | Yes | Available | 6000times | 5years |
36V 70AH | 525*275*220mm | 34kg | Yes | Available | 6000times | 5years |
36V 80AH | 525*275*220mm | 40kg | Yes | Available | 6000times | 5years |
36V 100AH | 522*270*215mm | 36kg | Yes | Available | 6000times | 5years |
36V 200AH | 530*495*425mm | 85kg | Yes | Available | 6000times | 5years |
What Clients Say about RJ ENERGY Batteries
RJ ENERGY Automatic Production Line
RJ ENERGY Batteries Wooden Package
CONTACT US GET A LATEST QUOTE NOW!
