8000CYCLES - 15YEARS WARRANTY - FACTORY PRICE
RJ 24v Lithium Iron Phosphate batteries (LiFePO4) are extremely powerful, capable of providing high discharge rates even at elevated temperatures. Safety is improved over other lithium ion chemistries due to its thermal and chemical stability, Many applications using sealed lead acid (SLA) are upgrading their battery power with RJ drop in replacement LiFePO4 battery.
Each battery has an internal Battery Management System (BMS) That protects the battery from Over Charging, Over Discharging, Short Circuit and over current, over temperature along with cell balancing to provide you with the best performance and longest life out of the battery.
This Product Is Perfect For Motorhomes, Travel Trailers, Fifth Wheels, Boats, Yachts, Sailing, Trolling Motors, Electronics, Solar Backup Power, and Other Deep Cycle Applications.
Items | Parameter |
Battery Type | LiFePO4 |
Nominal Voltage | 25.6V |
Nominal Capacity | 800Ah |
Energy | 20,480Wh |
Internal Resistance | ≤15mΩ |
Series & Parallel Application | Customized |
Limited Charge Voltage | 29.2V |
Floating Charge Voltage | 20V |
Charge Method | CC/CV |
Discharge Cut-off Voltage | 20V |
Charge Current | 200A (Customizable) |
Continuous Discharge Current | 800A (Customizable) |
Pulse Discharge Current | 1600A (Peak) |
Cycle Life | > 8000 cycles |
Dimension (mm) | Customizable ( can made with cabinet) |
Weight | 200Kg |
Charge Temperature Range | 0~55℃ |
Discharge Temperature Range | -20~65℃ |
Recommended Operating Temperature | 15~55℃ |
Recommended Storage Temperature & Humidity Range | 15~35℃,45~75%RH |
Features
• More than 8000 Cycles
• Battery modules available for parallel and series for higher voltage and capacity
• BMS Passive cell balance funciton
• IP66, IP67, water proof, dust proof, Temperature monitoring
• Customization for Size and Discharge and charge rate
• Free of Maintenance, contains no poisonous material
• No leakage, no hazardous chemistry
• Quick delivery
• Lighter in weight, smaller in size to save space.
• Powerfull to increase robust operation for your marine boat or RV
• Fast charging and high power discharge rate available
• No need to add water nor worry about maintenance.
Item
| Content | Criterion |
Over charge Protection
| Over charge detection voltage | 3.6~4.25V |
Over charge detection delay time | 0.1 S ~ 6S | |
Over charge release voltage | 3.5~4.25V | |
Over discharge protection | Over discharge detection voltage
| 2.0~3.3V |
Over discharge detection delay time | 0.1 S ~ 6S | |
Over discharge release voltage | 2.1~3.4V | |
Charge Over current protection | Charge Over current detection current | 1~100A |
Charge Over current detection delay time | 0.02S~ 6S | |
Discharge Over current protection | Discharge Over current detection current | 1~600A |
Discharge Over current detection delay time
| 0.02S~ 6S | |
Short protection | Short protection detection delay time | 100 u S |
Detection condition | B+ P-0.2 Omh | |
restore | Cut off load | |
Interior Resistance | Main loop electrify resistance | 2 OMh(50A) |
Currentconsumption | Current consume in normal operation | 1.5mA Type |
Currentconsumption | Current consume in sleep operation | 2 uA Type |
Note BMS is customizable. More advanced functions available, such as bluetooth, RS485, CAN, Automaticaly Heating functions, High temperature shut off, Low temperature shut off, BMS protocol available etc. Contact us for more details!
With powerful capacity of Lithium Battery production, RJ is able to provide 1 to 1 customization service. No matter you only buy 1 pcs battery for your own use, or you are a company looking for bulk order of LiFePO4 Battery Pack, RJ will always meet your full satisfactions!
Contact Us Customize your own battery Now!
Home Battery Powerwall Battery | ||||||
Rated Energy | Voltage | Installation | Communication | Weight | lifespan | Cylces |
5KWH | 24V | Wall/Floor | RS485/Bluetooth | 50KG | 30years | 8000times |
10KWH | 24V | Wall/Floor | RS485/Bluetooth | 100KG | 30years | 8000times |
15KWH | 24V | Wall/Floor | RS485/Bluetooth | 150KG | 30years | 8000times |
20KWH | 24V | Wall/Floor | RS485/Bluetooth | 200KG | 30years | 8000times |
25KWH | 24V | Wall/Floor | RS485/Bluetooth | 250KG | 30years | 8000times |
30KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 300KG | 30years | 8000times |
35KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 350KG | 30years | 8000times |
40KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 400KG | 30years | 8000times |
45KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 450KG | 30years | 8000times |
50KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 500KG | 30years | 8000times |
55KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 550KG | 30years | 8000times |
60KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 600KG | 30years | 8000times |
65KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 650KG | 30years | 8000times |
70KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 700KG | 30years | 8000times |
75KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 750KG | 30years | 8000times |
80KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 800KG | 30years | 8000times |
85KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 850KG | 30years | 8000times |
90KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 900KG | 30years | 8000times |
100KWH | 24V | Wall/Floor/Rack | RS485/Bluetooth | 1000KG | 30years | 8000times |
Factory Price- Customization available- MOQ1pcs-15Years warranty | ||||||
1. Our company is a high-tech enterprise with 10 years’ experience in R&D battery.
2. With a total span of 20000 square meters, our monthly production capacity can exceed 6,000,000 Ah in our factories.
3. Flexible customizing and manufacturing accepted.
4. We promise providing high quality products with our professional R&D team, accomplished and experienced workers and advanced equipment.
5. Strict management and control for every progress in producing and 100% QC inspection before shipment.
6. We provide service of sample and prompt shipment, and sending someone to follow up the logistics progress after delivery.
7. 10 years warranty. Professional after-sales service, give instruction on how to use the products.
CONTACT US GET A LATEST QUOTE NOW!
