RJ-LFP-24200-RV
RJ
RJ-LFP-24200-RV
8000CYCLES - 10YEARS WARRANTY - FACTORY PRICE
RJ 24V battery is designed with LiFePO4 cells this Replacement Battery Pack is an extreme upgrade to any Lead-Acid battery system in your RV, Golf Cart, Solar, or Off-Grid Power Application.
By upgrading to RJ 24V lithium RV Battery pack, you will have More Capacity, More Power, Faster Charging Capabilities, Lighter Payloads, Longer Cycle-Life and the lowest carbon footprint.
RJ 24V RV batteries are designed to last up to 20 years with Zero Maintenance Required. LED Display or Bluetooth , Compact Modular Design, High Temp Operating Range, Best Power Density/Pack Size, Best Aluminum Mosfet Design, Short Circuit Protection. In both short and long-term, we guarantee that you will see and feel the LiFePO4 difference!
Items | Parameter |
Battery Type | LiFePO4 |
Nominal Voltage | 25.6V |
Nominal Capacity | 200Ah |
Energy | 5120Wh |
Internal Resistance | ≤15mΩ |
Series & Parallel Application | up to 10 parallel connected application |
Limited Charge Voltage | 29.2V |
Floating Charge Voltage | 20V |
Charge Method | CC/CV |
Discharge Cut-off Voltage | 20V |
Charge Current | 60A (Customizable) |
Continuous Discharge Current | 100A (Customizable) |
Pulse Discharge Current | 200A (Peak) |
Cycle Life | > 6000 cycles |
Dimension (mm) | 485mm*271mm*232mm(Customizable) |
Weight | 45Kg |
Charge Temperature Range | 0~55℃ |
Discharge Temperature Range | -20~65℃ |
Recommended Operating Temperature | 15~55℃ |
Recommended Storage Temperature & Humidity Range | 15~35℃,45~75%RH |
Features
• More than 8000 Cycles
• Battery modules available for parallel and series for higher voltage and capacity
• BMS Passive cell balance funciton
• IP66, IP67, water proof, dust proof, Temperature monitoring
• Customization for Size and Discharge and charge rate
• Free of Maintenance, contains no poisonous material
• No leakage, no hazardous chemistry
• Quick delivery
• Lighter in weight, smaller in size to save space.
• Powerfull to increase robust operation for your marine boat or RV
• Fast charging and high power discharge rate available
• No need to add water nor worry about maintenance.
No. | Item | Test Item | Creterion | |
1 | Voltage | Charging Voltage | DC:29.2V CC/CV | |
Balance voltage for single cell | 3.50±0.025V | |||
2 | Current | Balance voltage for single cell | 35±5mA | |
Current consumption | ≤50μA | |||
Charging current | 100A | |||
Rated continuous discharging current | 100A (Peak 200A) | |||
3 | Over charge Protection | Over charge detection voltage for single cell | 3.65V±0.025V | |
Over charge detection delay time | 0.7S—1.3S | |||
Over charge release voltage for single cell | 3.550±0.05V | |||
4 | Over discharge Protection | Over discharge detection voltage for single cell | 2.50V±0.07V | |
Over discharge detection delay time | 1.6±0.5S | |||
Over discharge release voltage for single cell | 3.00±0.75V | |||
5 | Over current Protection | Over current detection current | 300±50A | |
Over current detection delay time | 1.6±0.5S | |||
Release condition | Cut load | |||
6 | Short Protection | Detection condition | Exterior short circuit | |
Detection delay time | 230uS—500uS | |||
Release condition | Cut load | |||
7 | Resistance | Protection circuitry (MOSFET) | ≤60mΩ | |
8 | Temperature | Operating Temperature Range | -40~+85℃ | |
Storage Temperature Range | -40~+125℃ |
Note BMS is customizable. More advanced functions available, such as bluetooth, RS485, CAN, Automaticaly Heating functions, High temperature shut off, Low temperature shut off, BMS protocol available etc. Contact us for more details!
With powerful capacity of Lithium Battery production, RJ is able to provide 1 to 1 customization service. No matter you only buy 1 pcs battery for your own use, or you are a company looking for bulk order of LiFePO4 Battery Pack, RJ will always meet your full satisfactions!
Contact Us Customize your own battery Now!
LIFEPO4 | Dimensions | Weight | with BMS | Bluetooth/RS485 | Life Cycles | Lifespan |
24v 10AH | 98*165*175mm | 2kg | Yes | Available | 8000times | 30years |
24v 20AH | 120*158*190mm | 5kg | Yes | Available | 8000times | 30years |
24v 30AH | 165*175*220mm | 8kg | Yes | Available | 8000times | 30years |
24v 40AH | 165*175*220mm | 10kg | Yes | Available | 8000times | 30years |
24v 50AH | 265*237*215mm | 13kg | Yes | Available | 8000times | 30years |
24v 60AH | 265*240*215mm | 15kg | Yes | Available | 8000times | 30years |
24v 75AH | 261*270*215mm | 18kg | Yes | Available | 8000times | 30years |
24v 80AH | 260*273*225mm | 20kg | Yes | Available | 8000times | 30years |
24v 100AH | 175*540*160mm | 25kg | Yes | Available | 8000times | 30years |
24v 120AH | 221x450x225mm | 30kg | Yes | Available | 8000times | 30years |
24v150AH | 221*450*225mm | 38kg | Yes | Available | 8000times | 30years |
24v 200AH | 400*500*160mm | 50kg | Yes | Available | 8000times | 30years |
24v 300AH | 400*500*350mm | 75kg | Yes | Available | 8000times | 30years |
24v 400AH | 400*500*350mm | 100kg | Yes | Available | 8000times | 30years |
24v 500AH | Standard 19in Rack | 125kg | Yes | Available | 8000times | 30years |
24v 600AH | Standard 19in Rack | 150kg | Yes | Available | 8000times | 30years |
24v 800AH | Standard 19in Rack | 200kg | Yes | Available | 8000times | 30years |
24v 1000AH | Standard 19in Rack | 250kg | Yes | Available | 8000times | 30years |
Self-heated Function (Optional)
To relieve winter range anxiety in some freezing environment, the BMS can bring with
self heating function. Resistance heating rapidly warms the inside of battery.
Start heating temperature:≤0°C. Stop heating temperature:≥10°C.
Can improve battery charge / discharge performance.
you to read battery status freely anytime via your smart phone.
1. Our company is a high-tech enterprise with 10 years’ experience in R&D battery.
2. With a total span of 20000 square meters, our monthly production capacity can exceed 6,000,000 Ah in our factories.
3. Flexible customizing and manufacturing accepted.
4. We promise providing high quality products with our professional R&D team, accomplished and experienced workers and advanced equipment.
5. Strict management and control for every progress in producing and 100% QC inspection before shipment.
6. We provide service of sample and prompt shipment, and sending someone to follow up the logistics progress after delivery.
7. 10 years warranty. Professional after-sales service, give instruction on how to use the products.
CONTACT US GET A LATEST QUOTE NOW!
