72V 80Ah Lithium Iron Phosphate Battery For Electric Vehicles Golf Cart Forklift Motorcycles

72V 80Ah LiFePO4 Battery With BMS 6000Cycles For Electric Forklift Boat AGV Golf Cart
Material:
Voltage:
Capacity:
Lifecycle:
Availability:
Quantity:
  • RJ-LFP-7280-E

  • RJ

  • RJ-LFP-7280-E

                                         6000CYCLES - OEM / ODM - FACTORY PRICE



Lithium batteries have the advantages of light weight and low maintenance, making them the preferred choice for power supply for low speed electric vehicles. Since the lithium battery can provide the same voltage as the lead-acid battery, the user does not need to modify the electric golf cart or the E-forklift E-boat.

Lithium iron phosphate batteries have become a new trend in industrial batteries. Compared with traditional lead-acid batteries, lithium batteries have a large qualitative change and are a more environmentally friendly energy solution.

Although the initial battery replacement cost is slightly higher, the advantages of lithium batteries will save users more money during later use.

90


72v80ah-3


Norminal Power(KWh) 5888Wh
Norninal Capacity(Ah) 80Ah
Norninal Voltage(V) 72V
Type LiFePO4 Battery
Dimensions (mm) Customized
Weight(Kg) 58Kg
Discharging Voltage(V) 57.5~83.9V
Discharging Voltage(V) 57.5~83.9V
Charging 30A
Discharging Current (A) 80A
Working Temperature(℃) 0~55℃
Shelf Temperature(℃) -20~70℃
Humidity 0-95% RH(Non-condensing)
IP Grade (IP) 0-95% RH(Non-condensing)
Altitude ≤3000m
Authentication Level TuV/CE/UN38.3
Design Life(year) 20+ years (@25℃/77℉)
Cycle Life (cycle) >6000Times

72v80ah-2




72v80ah-4

Features

•          More than 6000 Cycles

•          Battery modules available for parallel and series for higher voltage and capacity

•          BMS Passive cell balance funciton

•          IP66, IP67, water proof, dust proof, Temperature monitoring

•          Customization for Size and Discharge and charge rate

•          Free of Maintenance, contains no poisonous material

•          No leakage, no hazardous chemistry

•          Quick delivery

•          Lighter in weight, smaller in size to save space.

•          Powerfull to increase robust operation

•          Fast charging and high power discharge rate available

•          No need to add water nor worry about maintenance.



BMS

Item



Content Criterion
Over charge
 Protection



Over charge detection voltage 3.6~4.25V
Over charge detection delay time 0.1 S ~ 6S
Over charge release voltage 3.5~4.25V
Over discharge protection

Over discharge detection voltage



2.0~3.3V
Over discharge detection delay time 0.1 S ~ 6S
Over discharge release voltage 2.1~3.4V
Charge
Over current protection
Charge Over current detection current 1~100A
Charge Over current detection delay time 0.02S~ 6S

Discharge

Over current

protection

Discharge Over current detection current 1~600A

Discharge Over current detection delay time



0.02S~ 6S

Short

protection

Short protection detection delay time 100 u S
Detection condition B+ P-0.2 Omh
restore Cut off load
Interior Resistance Main loop electrify resistance 2 OMh(50A)
Currentconsumption Current consume in normal operation 1.5mA Type
Currentconsumption Current consume in sleep operation 2 uA Type





LIFEPO4 Dimensions Weight with BMS RS485/Bluetooth Cycles Warranty
72V 10AH 195*165*175mm 13kg Yes Available 6000times 5years
72V 20AH 330*175*220mm 20kg Yes Available 6000times 5years
72V 30AH 485*175*240mm 32kg Yes Available 6000times 5years
72V 40AH 525*240*215mm 43kg Yes Available 6000times 5years
72V 50AH 505*273*225mm 48kg Yes Available 6000times 5years
72V 60AH 350*540*160mm 50kg Yes Available 6000times 5years
72V 70AH 350*540*160mm 58kg Yes Available 6000times 5years
72V 100AH 600*200*300mm 50kg Yes Available 6000times 5years
72V 200AH 179*1448*282mm*2pcs 220kg Yes Available 6000times 5years
72V 300AH 800*400*300mm*2pcs 260kg Yes Available 6000times 5years
